- Input Impedance : Balance : 20KΩ

- Output Impedance : Balance : 100Ω

- PC Com Port : One USB Com Port on front panel, 2 Rs485

Com Port on back panel(RJ-45)

- CMRR : >70dB@1KHz

- Input Range : ≤±25dBu

- Frequency Response : 20 ~ 20KHz ±0.5dB

- S/N R : >110dB

- T.H.D : <0.01 output=0dBu/1KHz

- Crosstalk of Channels : >80dB@1KHz

- Delay Time Step : Each input channel has single delay control, Range:0~1000mS; 21uS step@0~10mS; 84uS step@ 10mS~20Ms;0.5mS step@ 20mS~1000mS

- Input/Output Polarity : In-phase(+) or reversed phase(-)

- Input EQ : 6-band parameter EQ; Frequency:20Hz~20KHz; Gain:-20dB; Bandwidth;0.05oct~3oct

- Input Gain : Input Gain Range:-80dB~+12dB, step@0.1dB

- Mute : Mute with each Input&Output channel

- Input Selection : Each input channel can be selected to each output channel

- Output Gain : Range : -80~12dB, step:0.1dB

- Output delay : Every input channel has independent delay control, adjust range:0~1000ms, step over: 21us@<10ms, ; 10ms~20ms, step over:84us @>20ms, step over:0.5ms

- Crossover : Ench output channel can be independently set as LPF and HPF. The parameters can be adjusted. Filter type : Linkwitz-Riley; Bessel; Butterworth. The Crossover Frequency:20Hz ~20KHz, Slope:12dB/oct; 18dB/oct; 24dB/oct;

30dB/oct; 36dB/oct; 42dB/oct; 48dB/oct;

- Limiter : Limiter with each output channel. The para meters are adjustable: Threshold value:-40dBu

~+20dBu; step:0.5dBu. Attack time:0.3mS~200 ms. 0.1mS step@0.3~1mS; 1mS step @1mS~

100mS. Release Time: Release Time can be set

to 50ms~500ms

- Output EQ : Each output channel has 6-band EQ: 3modes: Lo- Shelf/Hi-Shelf/Parameter.

A : Lo-Shelf: Slop: 6dB/12dB; Frequency:20Hz~20KHz; Gain: -20dB~20dB;

A : Hi-Shelf: Slop: 6dB/12dB; Frequency:20Hz~20KHz; Gain: -20dB~20dB;

C : Parameters: Frequency:20Hz~20KHz, bandwidth: 0.05oct~3oct; Step:

0.05oct;

Gain : -20dB~+20dB, Step 0.1dB

- Processor : 96KHz Sampling frequency, 32-bit Floating-Point

DSP 24-bit A/D and D/A converter

- Power : ≤25W

- Power Supply : AC 110V/220V 50Hz/60Hz

- Dimension(WxHxD) : 482 x 44 x 200mm±5%

- Weight : 3.5Kg
